| Prism type |
. |
Schmidt-Pechan |
| Magnification |
. |
8x |
| Field of view (FOV) at 1.000y |
. |
428 |
| Field of view (FOV) at 1.000m |
. |
143 |
| Objective diameter(mm) |
Effective diameter |
42 |
| Ocular diameter (mm) |
Effective diameter |
23,7 |
| Exit pipe diameter (mm) |
Measurement of the pubic ocular beam |
5,25 |
| Eye Relief (inches) |
From the last optical surface |
0,7 |
| Eye Relief(mm) |
From the last optical surface |
18 |
| Housing |
Main body and hinge |
magnesium |
| Close focus (feet) |
Shortest focal distance |
5,9 |
| Close focus (meters) |
Shortest focal distance |
1,8 |
| Interpupilary distance (IPD) |
Center pupil to center pupil measurement |
56 – 75 |
| Dioptric compensation range |
. |
-2.5/+2.5 |
| Waterproof |
Mbars/cm |
100 |
| Transmission Daylight |
ISO 14490-5:2005 |
90% |
| Height (inches) |
Without covers |
2,26 |
| Height(mm) |
Without covers |
55 |
| Weight (ounces) |
Without covers |
26,1 |
| Weight (grams) |
Without covers |
740 |
| Length (inches) |
At outside diameter |
5,4 |
| Length(mm) |
At outside diameter |
138 |
| Width (inches) |
Fully extended |
5 |
| Width(mm) |
Fully extended |
127 |
| Accessories included with the purchase |
. |
Instruction manual, cleaning cloth, hard
case, neoprene neck strap, hard case
Strap, objective covers, ocular covers |
